Fein KBM 65 U Automatic Magnetic Core Drill 230v

Description

Product Description of the Fein KBM 65 U Automatic Magnetic Core Drill 230v

Metal core drilling unit up to 65 mm
KBM 65 U
Powerful and very high-performance 2-speed universal magnetic core drill with clockwise/anti-clockwise operation, MT3 tool mounting, fine adjustment and maximum functionality for flexible working in the workshop.

Specifications:
Input 1,300 W
Output 730 W
Load speed in speed 1 120 - 240 rpm
Load speed in speed 2 260 - 520 rpm
Tool Holder MK 3
Carbide core drill bit max. dia. 65 mm
HSS core drill max. dia. 45 mm
Core drill, drilling depth max. 50(75)* mm
Twist drill max. dia. 25/ mm
Tapping M 20
Countersinking max. dia. 50 mm
Reaming max. dia. 25 mm
Core drill holder QuickIN
Changing the core bit tool-free
Stroke 145 mm
Total stroke range 315 mm
Adjustment range for drill jigs 6 mm
Swivel range for drill jigs 7?
Magnetic holding power 14,000 N
Magnetic foot dimensions 205 x 95 mm
Cable with plug 4 m
Weight according to EPTA 16.10 kg

Price includes:
1 coolant tank
1 lashing strap
1 swarf hook
1 centering pin
1 contact guard
1 drift key
1 case
