Description
Product Description of the Chicago Pneumatic CP3550-120ACC Die Grinder, 1/4" Collet
Industrial angle die grinder
Industrial grade durability with up to a 1,000 hour maintenance interval
Superior torque for maximal productivity
Superior ergonomics
Features
1.5 hp (1,100 W) governed motor
Durable bevel gear
Spindle lock button
1/4" (6.35 mm) collet holder
12,000 rpm free speed
Streamlined safety lever
Dimensions | 103 cm |
---|---|
Tool Type | Die Grinder |
Length | 249mm |
Item Weight | 1.5 kg |
Actual Air Consumption | 26 l/s [56 cfm] |
Free Speed Air Consumption | 17 l/s [36 cfm] |
Air Inlet Thread Size | 3/8" |
Min. Hose Diameter | 13 mm [1/2"] |
Sound Power | 95 db(A) |
Vibration Level (Test Method) | 6.1 m/s² (ISO-28927-12) |
Uncertainty (Test Method) | 7.3 m/s² (ISO-28927-12) |
Collet Size | 1/4" |
Max. RPM/SPM | 12000 |
Power | 1.4hp [1050 W] |
On-Site Tool Demonstration of the Chicago Pneumatic CP3550-120ACC Die Grinder, 1/4" Collet
Free On-Site UK Tool Demonstrations
Please complete the form below to arrange a tool demonstration for the Chicago Pneumatic CP3550-120ACC Die Grinder, 1/4" Collet or any of the Chicago Pneumatic range of tooling. Alternatively please call us on 01273 855119.Book a Tool Demonstration
Vibration Readings for the Chicago Pneumatic CP3550-120ACC Die Grinder, 1/4" Collet
Vibration readings for the Chicago Pneumatic CP3550-120ACC Die Grinder, 1/4" Collet are dependent on a number of factors that include the abrasive being used, the job in hand and operator experience. RedBlackTools or Chicago Pneumatic cannot be held responsible for the consequences of using the listed values for risk assessment, rather than actual values unique to each situation.
Vibration Level | Uncertainty | Vibration Test Method | |
Current (3 Axis) | 6.1 m/s² | 7.3 m/s² | ISO-28927-12 |
Would you like this data in an email?
Simply fill out the form below and the vibration data for the Chicago Pneumatic CP3550-120ACC Die Grinder, 1/4" Collet will be sent to your email automatically.
You can down load the HSE leaflet that explores the jobs which are affected; how to assess and control the risk; what employees need to know; and health surveillance measures. It will help you understand what you need to do to comply with the Control of Vibration at Work Regulations 2005 (The Vibration Regulations 2005).
Health and Safety Executive: Hand-Arm Vibration Guide
Please Note: Vibration and sound levels shown are the result of laboratory testing in conformity with European codes and standards, but are not sufficient for risk evaluation. Values measured in a specific workplace may differ from declared values. Actual exposure values and associated risk will be unique to each workplace and workstation. Potential risk to each individual depends on a variety of factors such as workstation design, surrounding environment, operator proficiency, material being worked and amount of exposure time. The employer is responsible for adhering to any applicable legal requirements regarding workplace health and safety and for evaluation of actual vibration and sound levels based on factors affecting the workplace environment. RedBlackTools or Chicago Pneumatic cannot be held responsible for the consequences of using the listed values for risk assessment, rather than actual values unique to each situation.
Sound and Decibel Readings of the Chicago Pneumatic CP3550-120ACC Die Grinder, 1/4" Collet
Noise Level | Sound Power |
84 db(A) | 95 db(A) |
The Control of Noise at Work Regulations 2005 (Noise Regulations 2005) require employers to prevent or reduce risks to health and safety from exposure to noise at work.
Would you like this data in an email?
Simply fill out the form below and the vibration data for the Chicago Pneumatic CP3550-120ACC Die Grinder, 1/4" Collet will be sent to your email automatically.
